IGS Audio V8 Compressor – Thomann Ireland

Discrete 2-Channel Bus Compressor

• 6 IGS custom transformers (3 per channel)
• HP filter in the sidechain circuit to filter low frequencies before the compression stage (OFF, 40, 80, 120, 180, 240, 320 Hz)
• Analog VU meter
• Sepped Elma manipulators
• +10THR switch lowers the compressor's threshold level by 10 dB
• Frequency range: 10 Hz - 25 kHz (+0. 2 dB / -0.4 dB)
• Operating level +4 dBu
• Max input level > +22 dBu
• Max output level > +26 dBu
• Dynamic range: 101 dBA (@ 1 kHz, +24 dBu)
• Max gain: 22 dB
• Max gain reduction: 30 dB
• Attack: 0. 1 ms - 30 ms
• Release: 0.1 s to 1.4 s + Auto
• Bypass Switch
• Integrated power supply 115/230V AC, 50-60 Hz
• 2 Line inputs: XLR
• 2 Line outputs: XLR
• Dimensions: 70 x 50 x 30 cm
• Weight: 8 kg
